High performance spindle incremental encoders -

for use on synchronous motor spindles with strong magnetic environments

VS Sensorik encoders are characterized by the traditional German style:

robustness, precision, excellent signal resolution, immunity to electromagnetic interference and are particularly suitable for
Electric spindles with synchronous motors (resistant to vibration, impact, ESD in strong magnetic fields)

Solutions for machine tool spindle encoders
Encoders in working condition need to be equipped with the corresponding signal transmitting device, usually the customer

is equipped with a code plate with different modulus and number of teeth.

In addition, we offer the following technical solutions according to customer needs:
Code discs: available in module M=0.3, 0.4 and 0.5, or on a custom basis.
The encoder housing is all-metal, but can be customized according to the customer's needs.
Cables for signal connection and temperature measurement are available for different control systems.
The encoder data can be collected and analyzed with VS' exclusive DCMU external encoder signal measurement box.
The encoder signal parameters can be adjusted via the PuV interface using an external device such as the HCU500

portable handheld toolbox.

The external measuring device DCMU-BOX can be used for quality control and mobile collection and analysis of the

spindle operating signals as well as for monitoring the condition of the codeplate Condition (intact or not)

VS encoders are made in Germany. Our quality products have a long service life;
We often encounter machine tool customers who find during spindle maintenance that the VS encoders have outlived

many other components but are still in use. Many other components are still in use.

As we are constantly replacing our products, please note if you have an old encoder that needs to be replaced:
Encoders with the model numbers MGK2M, KWG2M, KWG2D, RGK2M, etc. are still available, or we can help you with

New and improved products compatible with these models are available.
For the SIZAG and SIMAG series used in Siemens systems, we offer new compatible encoders.
For all M=0.3, 0.4, 0.5 modulo discs we offer compatible solutions (size and design) for encoder readheads.

This is especially true for discs with different reference signal types.
We offer a wide range of discs in modulo M=0.8, 1.0. Solutions from dimensional design to encoder readheads (e.g.

replacement of older models FP-210)
